Your Location : Home » PROJECT » Automatic Bag-on-valve Aerosol Filling Machine
Automatic Bag-on-valve Aerosol Filling Machine for in USA
AB-2A Automatic Bag-on-valve Aerosol Filling Machine
Description:
AB-2A Automatic Bag-on-valve Aerosol Filling Machine absorbs foreign advanced technology, charging compressed air (or N2) under cap and valves sealing is the first step by PLC control and touch screen interface, and then raw materials are filled. The machine has the feature of fast speed, easy operating, accurate dosage, reliable sealing and inflation pressure can be adjusted freely. The machine could be integrated with Automatic Weighing Machine, Automatic Water-bath Leakage Tester, Automatic Pressure Actuator, Automatic Cap Presser, automatic printer into one automatic line.
Specifications:
Model
AB-2A
Filling capacity
20-450ml (can be customized)
Filling accuracy
≤±1%
Available valve
1〞
Production capacity
800-1200 cans/hr
Air source
0.6Mpa-0.8Mpa clean and stable air source
Can Height
60~350
Can Diameter
Φ16~Φ100
Weight
about 250kg
Dimension(L×W×H)
8000×1200×2100
