Automatic Weight Checker

Description : Aerosol Can Weight Checking Machine

  • Features:
  • AWC-80 Automatic Weight Checker adopts stable and highly sensitive weighing sensor and signal acquisition instrument, carries out high-speed operation processing by applying a PLC,







AWC-80 Automatic Weight Checker


Automatic aerosol can weight checking machine / weight checker




AWC-80 Automatic Weight Checker adopts stable and highly sensitive weighing sensor and signal acquisition instrument, carries out high-speed operation processing by applying a PLC, is equipped with a visual and humanized man-machine interface and a well-designed transmission conveying mechanism, has the advantages of simple operation, good stability, high response speed, high accuracy, and so on, and is the best choice of on-line detection of finished weight.





Model

AWC

Production capacity

80 times/min

Power supply

AC380V

power

 0.8KW

Maximum detection weight

1.5KG

Machine division value

0.1G

Static deviation

0G

Dynamic detection maximum deviation

±1.0g

Air source

0.6Mpa-0.8Mpa clean and stable air source

Maximum air consumption

0.6m3/min

Can Height

60~350

Can Diameter

Φ16~Φ100

Weight

about 500kg

Dimension(L×W×H)

2000×1800×2100






Automatic aerosol can weight checking machine / weight checker




Model

AWC

Production capacity

80 times/min

Power supply

AC380V

power

 0.8KW

Maximum detection weight

1.5KG

Machine division value

0.1G

Static deviation

0G

Dynamic detection maximum deviation

±1.0g

Air source

0.6Mpa-0.8Mpa clean and stable air source

Maximum air consumption

0.6m3/min

Can Height

60~350

Can Diameter

Φ16~Φ100

Weight

about 500kg

Dimension(L×W×H)

2000×1800×2100
