AWT Automatic Water-bath Leakage Tester

Description : AWT Automatic Water-bath Leakage Tester

  • Features:
  • AWT Automatic Water-bath Leakage Tester is used for detecting various aerosol products, is not limited by can body materials, and can continuously detect the products completely.



AWT Automatic Water-bath Leakage Tester


AWT Automatic Water-bath Leakage Tester



AWT Automatic Water-bath Leakage Tester is used for detecting various aerosol products, is not limited by can body materials, and can continuously detect the products completely. Pressure in cans rises due to soaking in hot water, and individual aerosol cans with poor pressure resistance will be leaked, deformed or burst, thus being removed.



Model

AWT

Production capacity

3000-4200 cans/hr

Main driving head power

1.1KW

Water heating power

 33KW

Type of electric control box and heater

Explosion-proof

Temperature control accuracy

±1℃

Air source

0.6Mpa-0.8Mpa clean and stable air source

Maximum air consumption

0.6m3/min

Water tank capacity

1.2m³

Can Height

60~350

Can Diameter

Φ16~Φ100

Weight

about 1000kg

Dimension(L×W×H)

4000×1800×2100




AWT Automatic Water-bath Leakage Tester




Model

AWT

Production capacity

3000-4200 cans/hr

Main driving head power

1.1KW

Water heating power

 33KW

Type of electric control box and heater

Explosion-proof

Temperature control accuracy

±1

Air source

0.6Mpa-0.8Mpa clean and stable air source

Maximum air consumption

0.6m3/min

Water tank capacity

1.2m³

Can Height

60~350

Can Diameter

Φ16~Φ100

Weight

about 1000kg

Dimension(L×W×H

4000×1800×2100
