Your Location : Home » PROJECT » Semi-automatic Bag-on-valve Aerosol Filling Machine

Semi-automatic Bag-on-valve Aerosol Filling Machine in Turkey



Semi-automatic Bag-on-valve Aerosol Filling Machine(PLC)






Semi-automatic Bag-on-valve Aerosol Filling Machine in Turkey











Description:

AS-2A Semi-automatic Bag-on-valve Aerosol Filling Machine integrates the vacuum pumping, compressed air (or nitrogen N2) filling and sealing as a whole, and does the line pack of raw materials. It is especially suitable for water-based aerosol products filling. It is fast in speed, precise in filling volume and good in airtight seal, and the required inflation pressure can be adjusted at will. It can also be used as the medical care oxygen filling and the secondary recharging. It is equipped with PLC + touch screen for control.







Specifications:



Model

AS-2A

Filling capacity

20-450ml (can be customized)

Filling accuracy

 ≤±1%

Production capacity

800-1200 cans/hr

Air source

0.6Mpa-0.8Mpa clean and stable air source

Can Height

60~350

Can Diameter

Φ16~Φ100

Weight

about 250kg

Dimension(L×W×H)

900×500×1500





AS-2A Semi-automatic Bag-on-valve Aerosol Filling Machine

Semi-automatic Bag-on-valve Aerosol Filling Machine in Turkey
