Your Location : Home » PRODUCTS » Aerosol Line Supporting Equipment » ABD Automatic Ball Dropper

ABD Automatic Ball Dropper

Description : ABD Automatic Ball Dropper

  • Features:
  •  ABD Automatic Ball Dropper is formed by arranging a fixed ball bucket on a stepping main machine and is used for automatically feeding balls such as glass beads, and 1-4 beads can be automatically regulated.



ABD Automatic Ball Dropper

ABD Automatic Ball Dropper



 ABD Automatic Ball Dropper is formed by arranging a fixed ball bucket on a stepping main machine and is used for automatically feeding balls such as glass beads, and 1-4 beads can be automatically regulated.



Model

ABD

Feeding mode

natural leak

Diameter of glass beads

ø12, ø16, ø20 and so on

Bead filling number

1-4 beads/times

Applicable aerosol can diameter

 ø35-ø65mm

Applicable aerosol can height

90-315mm

Production capacity

2400-3600 cans/hr

Air source

0.6Mpa-1Mpa clean and stable air source

Max air consumption

0.2 M³/min

Weight

about 200kg

Dimension(L×W×H)

12000×1500×2100




 ABD Automatic Ball Dropper





Model

ABD

Feeding mode

natural leak

Diameter of glass beads

ø12, ø16, ø20 and so on

Bead filling number

1-4 beads/times

Applicable aerosol can diameter

 ø35-ø65mm

Applicable aerosol can height

90-315mm

Production capacity

2400-3600 cans/hr

Air source

0.6Mpa-1Mpa clean and stable air source

Max air consumption

0.2 M³/min

Weight

about 200kg

Dimension(L×W×H

12000×1500×2100
